Server Technology PRO2 Switched POPS STV-6542E - Power distribution unit (rack-mountable) - AC 208 V - 8.6 kW - 3-phase delta - Ethernet 10/100, RS-232 - input: NEMA L15-30 - output connectors: 24 (power IEC 60320 C13, IEC 60320 C19)

• Network monitoring
  Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more.
• Hot-swap network card
  Network access is ensured when power is lost to the Master unit with backup power provided by the primary link unit.
• Star multi-linking
  Provides the ability to link up to four power circuits using one IP address. Primary link provides backup power to network card.
• Auto-flip current display
  Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high-density cabinets.
• Branch current monitoring
  PRO2 monitors current at each breaker branch and provides SNMP-based alerts and emails on high usage that risks a tripped circuit.
• High retention locking outlets
  Receptacles have high retention and are compatible with P-Lock type power cords.

The Server Technology PRO2 Switched POPS PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS and POPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input and at each output. These power data points, along with temperature and humidity measurements, are accessible through the built-in web and CLI interfaces as well as through SNMP.

• Network monitoring
• Hot-swap network card
• Star multi-linking
• Auto-flip current display
• Branch current monitoring
• High retention locking outlets
