Server Technology PRO2 Switched PDU C2W42CE-2CAF2M00 - Master - power distribution unit (rack-mountable) - AC 208 V - 5 kW - 3-phase - Ethernet 10/100, RS-232 - input: NEMA L6-30P - output connectors: 42 (42 x IEC 60320 C13)

• Network monitoring
  Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more.
• Hot swappable
  Network access is ensured when power is lost to the Master unit with backup power provided by the primary link unit.
• Multi-link expansion
  Provides the ability to link up to four power circuits using one IP address. Primary link provides backup power to network card.
• Branch current monitoring
  PRO2 monitors current at each breaker branch and provides SNMP-based alerts and emails on high usage that risks a tripped circuit.
• Outlet control
  On Switched rack PDUs, cycle power to individual outlets or groups of outlets to reboot servers. Or, power off unused receptacles.
• High retention outlets
  Receptacles have high retention and are compatible with P-Lock type power cords.

The Server Technology PRO2 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input.
