Name: Server Technology PRO1 Switched PDU C1X16VS-1DFA17A5 - Link - power distribution unit (rack-mountable) - AC 120 V - 1.9 kW -
SKU: 338702

Product Details ＋

Server Technology PRO1 Switched PDU C1X16VS-1DFA17A5 - Link - power distribution unit (rack-mountable) - AC 120 V - 1.9 kW - Ethernet 10/100, RS-232 - input: NEMA L5-30P - output connectors: 16 (NEMA 5-20R)

Network monitoring
Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more.
Hot-swap network card
Network access is ensured when power is lost to the primary unit with backup power provided by the primary link unit.
Star multilinking
Provides the ability to link up to four power circuits using one IP address. Primary link provides backup power to network card.
Temperature / humidity monitoring
Primary and link units each support two external probes. Receive SNMP-based alerts and email notifications.
Auto-flip current display
Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high-density cabinets.
Per-inlet power sensing
PIPS includes voltage, active power, apparent power, power factor, and energy.
Outlet control
On switched rack PDUs, cycle power to individual outlets or groups of outlets to reboot servers. Or, power off unused receptacles.
High-retention locking outlets
Receptacles have high retention and are compatible with P-Lock type power cords.

The Server Technology PRO1 switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack / cabinet. The integral PIPS technology provides accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points are accessible through the built-in web and CLI interfaces as well as through SNMP.
